物理參數 / Physical Characteristics |
尺寸/Dimensions: | 115mm x 72mm x 210mm |
重量/Weight:? | ?266.2g |
外殼材質/Housing Material: | ?PC,TPU |
功耗/Power Consumption: | 2.5W max |
供電/Power Supply: | 5VDC |
識讀參數 / Performance Characteristics |
圖像傳感器/Image(Pixels): | 全局快門,1280 x 1080,?60FPS |
光源/Light Source: | 白色LED同軸光 |
視場角度/FOV: | ?水平12度 |
靈敏度/Roll/Pitch/Yaw: | ?旋轉(Roll)360° |
打印對比度/Print Contrast: | ≥15% |
通訊接口/Interfaces Supported: | RS232,USB COM,USB HID Keyboard |
識讀碼制 Decode Capability:
| 一維條碼/1D:Code128, Code93, Code39, Interleaved 2 of 5, Industrial 2 of 5, IAN/EAN/UPC |
二維條碼/2D:Vericode, QR, DataMatrix, PDF417, Aztec |
用戶環(huán)境 / User Environment |
溫度范圍/Temperature Range:? | 工作溫度:0°C~50°C, 存儲溫度:-20°C~70°C |
ESD防護/ESD Protection: | ?接觸放電:±8KV, 空氣放電:±15KV, 耦合放電:±8KV |
環(huán)境光免疫/Ambient Light Immunity: | ?100.000?Lux. |
